| 品牌：耐普 | 型号：NP2-500AH | 化学类型：铅酸蓄电池 |
| 电压：2V | 类型：固定型蓄电池 | 荷电状态：免维护蓄电池 |
| 电池盖和排气拴结构：阀控式密闭蓄电池 | 额定容量：500AH | 外型尺寸：详询客服mm |
| 适用范围：UPS蓄电池 |
规格表
| Model NO. | Nominal Voltage (V) | Rated Capacity(AH) 20hrs/25℃ | Approx. Weight | Dimensions(mm) | Terminal Type | ||||||||
| kg | lbs | Length | Width | Height | Total Height | ||||||||
| mm | inch | mm | inch | mm | inch | mm | inch | ||||||
| NP2-50Ah | 2 | 50 | 2.90 | 6.38 | 160 | 6.30 | 49 | 1.93 | 166 | 6.54 | T12 | ||
| NP2-100Ah | 2 | 100 | 5.6 | 12.3 | 171 | 6.73 | 71 | 2.80 | 207 | 8.15 | T6 | ||
| NP2-100Ah II | 2 | 100 | 5.9 | 13.0 | 171 | 6.74 | 71 | 2.80 | 207 | 8.16 | T6 | ||
| NP2-150Ah | 2 | 150 | 8.0 | 17.6 | 172 | 6.77 | 102 | 4.02 | 207 | 8.15 | T6 | ||
| NP2-200Ah | 2 | 200 | 13.5 | 29.7 | 172 | 6.77 | 111 | 4.37 | 329 | 13.0 | T20 | ||
| NP2-300Ah | 2 | 300 | 18.8 | 41.4 | 171 | 6.7 | 151 | 5.9 | 330 | 13.00 | T20 | ||
| NP2-400Ah | 2 | 400 | 26.7 | 58.7 | 210 | 8.27 | 176 | 6.93 | 329 | 12.96 | T20 | ||
| NP2-500Ah | 2 | 500 | 31.0 | 68.2 | 241 | 9.50 | 172 | 6.8 | 331 | 13.0 | T20 | ||
| NP2-600Ah | 2 | 600 | 38.0 | 83.8 | 301 | 11.9 | 175 | 6.89 | 331 | 13.0 | T20 | ||
| NP2-800Ah | 2 | 800 | 53.0 | 116.6 | 410 | 16.1 | 175 | 6.89 | 330 | 13.3 | T20 | ||
| NP2-1000Ah | 2 | 1000 | 63.0 | 138.9 | 475 | 18.72 | 175 | 6.90 | 330 | 13.00 | T20 | ||
| NP2-1200Ah | 2 | 1200 | 69 | 152 | 475 | 18.7 | 175 | 6.89 | 330 | 12.99 | T20 | ||
| NP2-1500Ah | 2 | 1500 | 101 | 223 | 401 | 15.80 | 351 | 13.83 | 342 | 13.5 | T20 | ||
| NP2-1800Ah | 2 | 1800 | 120 | 264.6 | 401 | 15.80 | 351 | 13.83 | 342 | 13.47 | T20 | ||
| NP2-2000Ah | 2 | 2000 | 120 | 264 | 401 | 15.8 | 351 | 13.8 | 342 | 13.51 | T20 | ||
| NP2-2500Ah | 2 | 2500 | 165 | 363.8 | 710 | 27.97 | 352 | 13.87 | 342 | 13.47 | T20 | ||
| NP2-3000Ah | 2 | 3000 | 195 | 429.9 | 710 | 27.97 | 352 | 13.87 | 342 | 13.47 | T20 | ||
